ГНОМ X — новейшая модель серии
The user himself can configure the underwater module and control system by installing the required number of thrusters, video cameras and other equipment.
Vehicle
.png)
ROV |
|
| Operating depth | 200 m |
| ROV dimensions | 420/470x380/400x270/300 mm |
| ROV weight | 5-10 kg |
| Thrusters | Horizontal thruster with lights (cluster 9xLED), Vertical thruster |
| Cruising speed up | 4 knots |
| lifting capacity | 3 kg |
Cable |
|
| Maximum cable length | 400 m |
| Cable diameter | 4,5 mm |
| Full system weight | 11 kg |
Camera |
|
| Camera type | 2 Cameras (FullHD/4K Front and FullHD/4K Rear) |
| Camera resolution | 700 TV lines |
| Matrix | 1/3 |
| Sensitivity | 0,01 lux |
| Focusing | yes |
| Camera tilt | ±70º |
LEDs |
|
| LEDs | 2-6 |
| Other | Variable intensity |
Equipment |
| Sensors | Digital compass, Depth sensor |
| Monitor | 21.5" IPS matrix |
| Management | Touch management |
